Sylodyn®
Sylodyn® by Getzner, the material for the most stringent requirements
Sylodyn®
Sylodyn® is used for vibration and noise protection, as well as various other applications.
Sylodyn is a versatile material that finds application in a wide range of scenarios, including railway line vibration protection, impact noise isolation, structural bearing, and noise reduction within buildings.
Its closed-cell elastomer nature and improved dynamic properties make it a valuable choice for projects where these properties are essential.
Advantages of Sylodyn®
Advantages of Sylodyn®, Vibration Protection.
- High dynamic load capacity.
- Static range of use for standard types from 0.075 N/mm2 to 1.5 N/mm2, special types to 12 N/mm2.
- Load peaks up to 24 N/mm2.
- Very low amplitude dependence.
- Low creep tendency.
- Stiffening factor (Cdyn/Cstat) from 1.15 to 1.40.
- Proven long-term behaviour.
- Fatigue strength.
- Finely graded range (8 standard types) for optimum system design.
- Ability to provide customer-specific modifications.
Vibration Protection
Sylodyn® is used as a vibration protection solution on local and inter-city railway lines, but also for isolating impact noise in floors and on stairs, as a bearing for buildings or machines, or for isolating noise between walls, floors and ceilings. Sylodyn® is a closed-cell elastomer that does not absorb water. In comparison to Sylomer®, the material offers improved dynamic properties.
- Pronounced spring characteristics.
- Closed cellular pore structure.
- Suitable for very high loads.
Key features of Sylodyn®
Vibration Protection on Railway Lines
Sylodyn® is used to reduce vibrations on both local and intercity railway lines. It effectively limits the transfer of vibrations from the track to surrounding structures, improving passenger comfort and helping to protect railway infrastructure from excessive wear.
Impact Noise Isolation
This material is also applied to isolate impact noise in flooring and staircases.
It absorbs and disperses the energy from footsteps and other impacts, helping to lower noise levels throughout a building.
Bearing for Buildings and Machines
Sylodyn® can be used as a bearing material for both buildings and machinery. It helps to evenly distribute loads and dampen vibrations, preserving structural integrity and supporting reliable machine performance.
Noise Isolation Between Walls, Floors, and Ceilings
Sylodyn® is used to reduce noise transfer between building components like walls, floors, and ceilings. It effectively minimises both airborne and structure-borne sound, helping to create quieter, more comfortable indoor spaces.
Closed-Cell Elastomer
Sylodyn® is a closed-cell elastomer, meaning it repels water rather than absorbing it. This makes it ideal for use in outdoor or moisture-prone environments where resistance to damp conditions is essential.
Improved Dynamic Properties
Sylodyn® delivers enhanced dynamic performance compared to Sylomer®, making it better suited for managing dynamic loads and vibrations more effectively.
Variety of Types
Sylodyn® is available in five standard types, each tailored to meet specific application needs. In addition, three Sylodyn® HRB HS variants are stocked, offering specialised properties for more demanding or unique requirements.
Sylodyn® Customization
Similar to Sylomer®, Sylodyn® can be adapted to suit specific project needs. Its flexibility makes it an ideal choice for a wide range of applications across various industries.
Sylomer®
Sylomer® is a leading technical material in the field of vibration isolation, primarily used to reduce vibrations and noise in various applications, including buildings, machines and railway lines. It offers several advantages, such as lower maintenance costs and improved comfort in areas affected by vibration.
Sylodyn®
Sylodyn® is a closed-cell elastomer used for vibration and noise protection, as well as various other applications. Sylodyn® is a versatile material that finds application in a wide range of scenarios, including railway line vibration protection, impact noise isolation, structural bearing, and noise reduction within buildings.
Sylodamp®
Sylodamp® is a highly effective material damping product, primarily focused on providing impressive impact insulation. Whether it’s used for machine damping or enhancing human comfort in different settings, Sylodamp® plays a valuable role in minimizing the disruptive effects of impacts and vibrations.
